TRANSMISOR DE TEMPERATURA 2 HILOS
Descripción
Measuring input for RTD temperature probe, thermocouple, resistor/potentiometer, resistance transmitter, and voltage Input and output are galvanically isolated Control LED (red/green) Configuration directly via USB cable (mini B) without additional auxiliary voltage Customer-specific linearization Detection of the min./max. process value (drag indicator function including point in time) Option to specify the temperature in °F for temperature sensors The dTRANS T05 T is available with screw terminals or spring-cage terminals .
Características principales
The transmitters record sensor signals from RTD temperature probes, thermocouples, resistance transmitters, or resistors/potentiometers. When using a resistor/potentiometer or RTD temperature probe, the sensor connection on the input side can be connected with a 2-wire, 3-wire, or 4-wire circuit. Voltage signals in the range from -100 to +1100 mV can also be recorded. Depending on the selected measuring input, the linear and temperature-linear linearization variants and the possibility of easily configurable customer-specific linearization are available. The output signal of the dTRANS T05 B is 4 to 20 mA. The dTRANS T05 T offers an output signal of 4 to 20 mA or 0 to 10 V. The measuring input and the output signal are electrically isolated from each other. It is possible to reverse the output signal in both types. The transmitter configuration with respect to probe type, connection technology of the probe, measuring range (user configurable), and linearization is carried out by means of a setup program on the PC. The connection to the PC is established via a USB interface which does not require additional auxiliary voltage. Via the USB interface, the min./max. process value and the min./max. operating temperature recorded by the transmitter can be read and the sensor wiring can be checked online. The operating status of the transmitter is indicated by a two-color control LED (red/green). The control LED is lit green during malfunction-free operation. If a malfunction such as a probe break occurs then the signal starts flashing.
