TRANSMISOR DE TEMPERATURA 4 HILOS
Descripción
Design width 17.5 mm or 22.5 mm Installation on DIN rail, 35 mm Universal measuring input Galvanic isolation Current output, voltage output 2 open collector outputs LCD display Measuring circuit monitoring NAMUR NE 43 Also available in Ex version Customer-specific linearization Configuration with setup program or keypad (LCD version) .
Características principales
JUMO dTRANS T02 transmitters are equipped with a micro-processor for digital signal processing. The input and the output are galvanically isolated. The device can be installed on DIN rails. Electrical connection is made using screw terminals for strands or wire (conductor cross section max. 2.5 mm²). Depending on the type, the output signal 0/4 to 20 mA or 0/2 to 10 V is provided linearized (temperature-linear), or optionally, reversed. The PC setup program, which is available as an accessory, can be used to program the transmitter (probe type, measuring range, output behavior, fine adjustment, customer-specific linearization). For types 707021/... and 707022/... it is also possible to program the limit value monitoring and the frequency output. Current and voltage output are provided directly at terminals. No work on the hardware is required.
