Medior de flujo

Descripción

For horizontal mounting Measuring -/switching range: 10 - 100 ... 4.000 - 40.000 L/h water 0,3 - 3,0 ...110 -1100 Nm³ /h air; Connection: flange DN 15 ... DN 100, ANSI 3/4 ...4 Material: st. st. 1.4404, option PTFE-lining Max. Pressure: PN 40 (16) bar, on request max PN 600 bar Max. Temperature: -40...+200 °C (-40...+350°C on request) Accuracy : ± 2 % of meas. value Options: contacts, analogue output, totalizer, Hart, Profibus PA, ATEX .
